SIZE

Height: 246.94 mm

Width: 156.7 mm

Depth: 7.85 mm

Weight: Approx. 440 g (including battery)

DISPLAY

Size: 10.4 inches*

Screen-to-body Ratio: 83.6%**

Resolution: FHD+ 2000 × 1200***, 225 PPI

Colour: 16.7 million colours saturation (NTSC): 70.8% (typical value)

Type:

LCD

IPS Touchscreen

4096 levels auto brightness adjustment

PROCESSOR: Qualcomm® Snapdragon™ 680

CPU: 4 × Cortex-A73 2.4 GHz + 4 × Cortex-A53 1.9 GHz

GPU: Adreno 610

OPERATING SYSTEM HarmonyOS 3

MEMORY

ROM: 32

RAM: 3

CAMERA

Rear camera:

5 MP (f/2.2 aperture, AF)

Image resolution: Up to 2592 × 1944 pixels

Video Resolution: FHD 1080P

Rear Camera Capture Mode:

Portrait/professional/panorama/watermark/time-lapse photography/smiling face snapshot/voice activation/scheduled photo shooting/Continuous shooting

Front camera:

2 MP (f/2.2 aperture, Fixed Focal)

Image resolution: Up to 1600 × 1200 pixels

Video Resolution: HD 720p

Front Camera Capture Mode:

Portrait/watermark/time-lapse photography/smiling face snapshot/Mirror reflection/voice activation/scheduled photo shooting

CONNECTIVITY

WLAN:

AGS5-L09:

FDD-LTE: B1/B3/B5/B7/B8/B18/B19/B20/B26/B28

TD-LTE: B38/B40/B41

WCDMA: B1/B2/B5/B6/B8/B19

GSM: B2/B3/B5/B8

WIFI/WAPI: 2.4GHz&5GHz,802.11a/b/g/n/ac

AGS5-W09:

WIFI/WAPI: 2.4GHz&5GHz/802.11a/b/g/n/ac

Bluetooth: Bluetooth 5.0

Bluetooth File Transfer: Supported

PC Data Synchronization: Supported

OTG: Supported (maximum output 5V/1A during reverse power supply)

USB: Type-C, USB 2.0

LOCATION

AGS5-W09: Not Supported

AGS5-L09: GPS/AGPS/GLONASS/BeiDou/GALILEO

Sensors

Gravity sensor, Ambient light sensor

MICROPHONES

1 microphone

SPEAKERS

2 speakers

AUDIO

HUAWEI Histen8.0

Audio File Format: *.mp3, *.mp4, *.3gp,*.ogg, *.amr, *.aac, *.flac, *.wav, *.midi

VIDEO

Video File Format: *.mp4, *.3gp

BATTERY

5100 mAh (typ.)

CHARGING

5V/2A charger

IN THE BOX

Tablet (Built-in battery)

Charger

Type-C Cable

Quick Start Guide

Warranty Card

Eject pin
